Forge Wisdom

Warborn sells steel. Here the house gives away how steel is made. Everything below is old, published, testable craft — no secret is kept back because it might cost us a sale. If you would rather build your own forge and forge your own sword than buy ours, this hall is for you, and you owe the house nothing for it.

Numbers are given as ranges because steel is not a recipe card — believe your supplier's datasheet over ours where they differ. Held to house law WB-GOV-024: what the house cannot defend, it refuses to say, and every refusal is printed at the foot of this page.

Forge Wisdom is the first of the March's three schools, beside the War Table and Sea Faring, reckoned together at The Convergence. Standing and access only — never Marks, never coin, never a discount. Convergent multi-curriculum competence gating — US application 19/791,538, patent pending.

The steels, and what each one is honestly for

Carbon, quench, heat, temper — and the truth the catalogs leave out.

1045

carbon 0.45%
Harden at
1500–1550 °F
Quench in
Water or brine (fast)
Temper at
400–500 °F

Wall-hangers, blunt trainers, axe bodies, thick single-hand blades.

Too little carbon to hold a keen edge for long, but very hard to break. Most cheap 'battle-ready' swords are 1045 and that is not always an insult.

1060

carbon 0.60%
Harden at
1475–1525 °F
Quench in
Fast oil (parks 50) or warm canola
Temper at
400–450 °F

The honest middle: cutting swords, machetes, working axes.

The best strength-to-forgiveness ratio for a first sword. It will take a real edge and still survive your mistakes.

1075 / 1080

carbon 0.75–0.80%
Harden at
1450–1500 °F
Quench in
Fast oil; brine only if you enjoy grief
Temper at
375–450 °F

Knives, seax, arming swords, hard-use choppers.

Near-eutectoid: it hardens evenly and deeply and is very tolerant of an imperfect heat. This is the beginner's steel that professionals never stop using.

1095

carbon 0.95%
Harden at
1450–1475 °F
Quench in
Fast oil, pre-warmed to 120–130 °F
Temper at
375–425 °F

Knives, hamon work, differentially hardened blades.

Takes a screaming edge and cracks if you look at it wrong. Shallow-hardening, which is exactly why it makes a beautiful hamon — and exactly why long blades in 1095 warp.

5160

carbon 0.60% + chromium
Harden at
1500–1525 °F
Quench in
Medium-fast oil
Temper at
400–500 °F

Long swords, greatswords, anything that must flex and come back.

Leaf-spring steel. The single most forgiving alloy for a sword-length blade — it bends where 1095 would shatter. If you are making your first sword over 30 inches, make it from this.

9260

carbon 0.60% + silicon
Harden at
1500–1550 °F
Quench in
Medium oil
Temper at
450–550 °F

Spring-tempered performance swords.

Silicon buys enormous elastic range: a 9260 blade can take a 90° bend and stand back up. Harder to grind, and it does not hold an edge like 1080.

L6 / 15N20

carbon 0.70–0.75% + nickel
Harden at
1475–1500 °F
Quench in
Fast oil
Temper at
400–450 °F

The bright layer in pattern-welded steel; premium tough blades.

The nickel resists etchant, which is why 15N20 shows silver against dark 1084 in damascus. L6 bainite is the toughest sword steel known — and the most difficult heat treat in the craft.

Wrought iron

carbon under 0.08%
Harden at
Forge weld at 2300 °F
Quench in
Does not harden
Temper at
n/a

Historical cores, guards, pommels, mail rings, fittings.

Cannot be hardened, will not hold an edge, and is nearly impossible to break. Historic swords were often an iron core with a steel edge welded on — not because smiths were poor, but because it worked.

Stainless (440C, AUS-8)

carbon varies + 13%+ chromium
Harden at
1850–1950 °F
Quench in
Plate quench, needs precise ramps
Temper at
300–400 °F

Knives. Not swords.

The house says this plainly: do not forge a sword-length stainless blade. The chromium carbides make long blades brittle and the heat treat needs a controlled atmosphere kiln. Stainless swords are decorative. Full stop.

Build the forge

Three forges, from twenty dollars to four hundred. All of them work.

The brake-drum coal forge

$40–$1202400 °F+ (weldable)Bituminous smithing coal or hardwood charcoal
  1. 1Take a car brake drum — the hub hole is your tuyere. Bolt it to a steel or heavy timber table at waist height.
  2. 2Under the hole, fit a short length of 2" black pipe with a tee: down-leg capped as an ash dump, side-leg to your blower.
  3. 3Blower: a cheap hairdryer or bathroom fan with a gate valve or sliding plate to throttle air. Air control IS heat control.
  4. 4Line the drum with a 1" pack of clay and wood-ash refractory (2 parts clay, 1 part sand, 1 part ash), dried slowly for two days.
  5. 5Build the fire: paper, kindling, then a mound of coal. Keep a coal wall around a hollow 'heart' — the work goes in the heart, never on top.

Why you would: Reaches forge-welding heat, costs almost nothing, and teaches you fire management as no gas forge can.

Why you would not: Smoke, clinker, and a fire that must be tended constantly. Not for an attached garage or a suburban yard on a still day.

The single-burner propane forge

$180–$4002200–2350 °FPropane, 20 lb tank, 0–30 psi regulator
  1. 1Shell: a 20 lb propane tank (fully purged and cut with water inside) or a 12" length of 8" pipe.
  2. 2Line with two 1" layers of 8 lb ceramic wool. RIGIDISE IT with colloidal silica before anything else — loose ceramic fibre is a lung hazard.
  3. 3Coat the wool with a hard refractory (Kastolite 30 or similar), 1/2", then paint on an infrared reflective coat (ITC-100 or Metrikote). This one step can add 200 °F.
  4. 4Burner: a 3/4" naturally aspirated venturi (a T-burner) or a forced-air burner from a small blower. Mount it tangentially, not straight down.
  5. 5Cast a hard firebrick floor. Leave both ends open with loose brick doors so long stock can pass through.

Why you would: Lights in thirty seconds, holds an even temperature, and lets you concentrate on the steel instead of the fire.

Why you would not: Rarely welds without flux and patience; propane costs add up; and carbon monoxide means ventilation is not optional.

The ground charcoal forge (the oldest way)

Under $202200 °F+Lump hardwood charcoal
  1. 1Dig a trench 12" long, 6" wide, 6" deep in bare earth. Line with clay if you have it.
  2. 2Run a steel pipe into one end at a shallow angle, its mouth 1–2" above the trench floor.
  3. 3Air from a hand-cranked blower, a bellows, or a fan. Gentle and steady.
  4. 4Fill with lump charcoal, light it, and keep the fuel piled deep — charcoal burns fast and the work must sit in the reducing zone, not the open flame.

Why you would: This is how every sword before 1700 was made. It costs nothing and it will teach you more about fire than any book.

Why you would not: Devours fuel, throws sparks, and has no walls to hold heat. It is a teacher, not a shop.

The tools

What is truly needed, what can be cheated, and what only money buys.

What you cannot do without

Five things. Everything else is convenience.

  • An anvil — or 100 lb of any steel$0–$600

    Mass under the hammer is what moves steel. Rebound matters more than horn or shape.

    The cheat: A cut-off length of railroad track stood ON END (not laid flat) gives you a better working face than a laid track and costs a case of beer at a scrapyard. A forklift tine is better still.

  • A cross-peen hammer, 2–3 lb$25–$60

    Heavier is not faster. A 2.5 lb hammer swung correctly for an hour beats a 4 lb hammer swung for ten minutes.

    The cheat: Dress the face convex and polish it — hammer marks are just a rough hammer face printed into your blade.

  • Tongs that actually fit your stock$30 each, or forge them

    A blade dropped from loose tongs at 2000 °F is how people lose feet. Fit the tongs to the stock, not the other way.

    The cheat: Your very first project should be a pair of tongs. It teaches drawing, bending, punching and riveting at once.

  • An angle grinder + a belt grinder$40 / $400–$1,400

    Ninety percent of a finished blade is grinding, not forging. The 2x72 belt grinder is the single biggest upgrade in the craft.

    The cheat: Start with files and a 4.5" angle grinder. Slow, honest, and it teaches your eye the geometry.

  • A quench tank and a tempering oven$20 / $60 (a used toaster oven)

    Heat treatment, not forging, decides whether your sword is a weapon or a crowbar.

    The cheat: A cheap kitchen thermometer in the toaster oven — never trust the dial. They lie by 75 °F routinely.

What you will want by the third blade

Buy these in this order, as money allows.

  • A hardy hole set: hot cut, fuller, bick$80+

    Fullers and shoulders by hand are misery; by hardy tool they are three heats.

  • A drill press$150

    Pin holes, guard slots, and pommel threading want a square hole, not a hopeful one.

  • A surface plate + straightedge$60

    You cannot straighten what you cannot see. Every blade warps in the quench.

  • A magnet on a stick$5

    Non-magnetic (the Curie point, ~1414 °F) is your free, dead-accurate temperature gauge.

  • A power hammer or hydraulic press$1,200+

    The difference between one blade a week and one blade a day. Not needed. Wanted, deeply.

The craft, chapter by chapter

Fire, forging, heat treatment, two full recipes, damascus, and safety.

Work in the dark

Judging heat by colour is impossible in daylight — a blade that looks orange in a sunlit doorway is 300 °F hotter than one that looks orange in a dim shop. Every smith who ruins steel in the summer learns this the same way. Shade your forge, or work at dusk.

The colours, and what they mean

Faint red ~1100 °F, too cold to move. Dark cherry ~1400 °F, the low edge of forging. Bright cherry to orange 1500–1700 °F, where you should be doing almost all your work. Yellow 1900 °F, forge only heavy sections here. White with sparks — that is your steel burning. Sparks coming off the work are carbon leaving it, and it does not come back.

Note: Craft-lore, calibrated to a dim shop. A pyrometer beats any eye.

The reducing fire

Too much air burns the surface of your steel away as scale and strips carbon from the skin — the exact carbon you need at the edge. Keep the fire fuel-rich, the work buried in the heart of the coals, never sitting in open flame above them. In a gas forge this means dialling the burner slightly rich until you see a soft feather of flame at the door.

The three-heat rule

Never hammer below dark cherry. Cold-working carbon steel opens micro-cracks along the edge that will not appear until the quench, when the blade splits and you blame the oil. When it goes dull red, back in the fire. Most beginners lose a blade to impatience in the last thirty seconds of a heat.

The deep hall

Nine parts: the edge, the forms, the fittings, the harness, proof, buying, history, and the road to making and dealing yourself.

Edge & upkeep

Geometry & the forms

Fittings, hafts & scabbards

Armour & the harness

Proof & testing

Buying without being cheated

The history of the steel

Becoming a maker

Becoming a dealer

When it goes wrong

Symptom, cause, cure — the faults every smith meets in the first year.

The blade cracked in the quench, usually with a ringing sound

Why: Too fast a quench medium for the alloy, cold oil, an un-radiused shoulder or sharp corner, an uneven heat, or hammering below dark cherry earlier in the day.

The cure: Warm the oil to 120–130 °F, match the medium to the alloy, radius every corner, and never cold-work carbon steel. A cracked blade cannot be saved; break it and read the grain to learn from it.

The blade warped like a banana coming out of the oil

Why: Uneven heating, entering the quench at an angle, swirling sideways, or uneven bevel thickness pulling one side harder.

The cure: Quench edge-first, straight down, no sideways motion. Straighten while still above about 400 °F, or clamp between blocks during the temper cycles and let the temper set it straight.

A file bites the hardened edge

Why: It did not harden. Too cold, too slow a quench, or too long between the fire and the oil.

The cure: Re-normalise, then re-harden hotter and faster — check with a magnet, and reduce the walk from forge to quench tank to under two seconds.

The edge chips out in use

Why: Over-hard, under-tempered, or ground too thin behind the edge for the work.

The cure: Temper 25–50 °F higher for two more hours, and thicken the edge angle by two or three degrees.

The edge rolls or dents instead of chipping

Why: Under-hard or over-tempered — the opposite failure.

The cure: Re-harden and temper lower. A rolled edge can be steeled straight in the field but it will roll again.

The blade will not take a sharp edge no matter how long you grind

Why: You are not reaching the apex — you are grinding the shoulder of the bevel, not the edge.

The cure: Raise a burr along the full length before changing grits. Colour the edge with a marker and look at where the abrasive actually removes it.

Deep scratches keep reappearing after fine grits

Why: You moved up a grit before the previous one had removed all of the one below it.

The cure: Change the direction of grinding with each grit, ninety degrees apart, and do not advance until every scratch runs one way.

The forge weld did not take

Why: Not hot enough, oxide in the joint, too little flux, or the first blow was too heavy.

The cure: Clean both faces bright, flux at a low red, bring to bright yellow with a reducing fire, and set the weld with light fast taps before you draw it out.

Sparks are coming off the steel in the fire

Why: You are burning it. Carbon is leaving and it does not come back.

The cure: Cut the burnt section off entirely. Turn the air down, bury the work deeper in the coals, and watch the colour.

The hilt rattles

Why: The peen has loosened, the grip core has compressed, or wood has dried and shrunk.

The cure: Re-peen carefully, or shim under the guard. Stop using it for cutting until it is solid.

Orange freckles keep coming back on a cleaned blade

Why: Pitting holds moisture, or the storage environment swings in humidity.

The cure: Polish the pits out or accept them, then store with a vapour-corrosion inhibitor and a stable temperature. Re-oil monthly.

The axe head keeps loosening on the haft

Why: The eye was never fully seated, the wedge is too short, or the haft has dried out.

The cure: Re-hang it properly — never soak a haft to swell it, which rots the wood and loosens worse. Seat the head fully on the shoulder and use a full-length wooden wedge.

The glossary

Every word the trade uses, in plain speech.

Annealing
Heating steel and cooling it as slowly as possible to leave it soft enough to file, drill and grind.
Austenite
The high-temperature phase of steel where carbon dissolves into the iron. You must reach it before you can harden anything.
Bainite
A tough intermediate structure formed by holding steel at a set temperature instead of quenching straight to cold. Difficult, and extremely tough.
Bevel
The ground plane running from the blade's flat down to the edge.
Billet
A block or stack of steel to be forged, especially a stack destined to be pattern-welded.
Bloomery
The pre-blast-furnace method of smelting iron directly from ore into a spongy bloom.
Burr
The wire of displaced steel raised along an edge that proves you have ground all the way to the apex.
Chape
The metal fitting protecting the tip of a scabbard.
Choil
The unsharpened notch or section of blade just forward of the handle.
Convex edge
An edge whose faces curve outward rather than meeting as flat planes. Stronger, and the standard for choppers and cutting swords.
Cross-guard
The transverse bar between grip and blade. Called the quillons when it is elaborated.
Crucible steel
Steel melted in a sealed crucible to a uniform high carbon content; the origin of wootz.
Curie point
About 1414 °F for plain carbon steel — the temperature at which it stops being magnetic. Your free thermometer.
Damascus
Properly, wootz crucible steel. Commonly and loosely, modern pattern-welded steel of two contrasting alloys.
Decarburisation
The loss of carbon from the steel's surface in an oxidising fire. It leaves a soft skin that will not harden.
Differential hardening
Hardening the edge while leaving the spine soft, usually by clay coating. Produces the hamon.
Distal taper
The thinning of a blade in thickness from hilt to tip. The most important dimension in a sword.
Drift
A tapered tool driven through a punched hole to open and shape it — how an axe eye is made.
Ferrule
A band of metal reinforcing the end of a grip or haft.
Flux
Borax or similar, melted onto a joint to dissolve oxide so a forge weld can take.
Fuller
A groove forged or ground along a blade to remove mass from the centre without losing stiffness. Not a blood groove.
Gambeson
The quilted textile garment worn under mail or plate. The most important piece of armour anyone owns.
Grain
The crystal size of the steel's structure. Fine grain is tough; coarse grain breaks. Normalising refines it.
Hamon
The visible boundary between hardened edge and soft spine on a differentially hardened blade.
Hardy hole
The square hole in an anvil that holds shank tools — hot cuts, fullers, bicks.
Hauberk
A mail shirt, typically knee- or thigh-length with sleeves.
HRC
Rockwell C hardness. 55–58 for a sword edge, 58–61 for a knife, above 64 is brittle in a large blade.
Kydex
A thermoformed plastic sheath material: waterproof, washable, and completely anachronistic on a medieval piece.
Lame
A single articulated plate in an armour joint.
Martensite
The hard, brittle structure formed when austenite is cooled fast enough. Hardening means making martensite; tempering means taming it.
Munitions armour
Mass-produced, unfitted armour issued in quantity. Plain, heavier, and entirely functional.
Nagel
The side nail or guard projecting from the hilt of a messer.
Node
A point of minimum vibration along a blade. A good sword places one in the hand and one near the striking zone.
Normalising
Heating past critical and cooling in still air, repeated, to refine grain after forging. Never skip it.
Oakeshott typology
The standard classification of European medieval sword blades, types X through XXII.
Patina
A stable dark oxide on carbon steel that protects the surface. Not rust, and not neglect.
Pearlite
The soft layered structure of slowly cooled steel. What the clayed spine of a hamon blade stays as.
Peening
Cold-hammering the end of a tang over the pommel into a rivet that locks the hilt together.
Point of balance
The blade's balance point measured from the guard. Usually 3–5 inches on a single-hand sword.
Point of percussion
The zone along the blade where a strike produces the least shock in the hand. Cut here.
Quench
The fast cooling that turns austenite into martensite. Medium and temperature must match the alloy.
Quillon
One arm of an elaborated cross-guard.
Rat-tail tang
A thin rod, often welded to the blade and threaded. The classic failure point of a decorative sword.
Ricasso
The unsharpened flat just above the guard, used for half-swording or for a finger over the guard.
Riveted mail
Mail whose rings are each closed with a rivet. The only historically and practically sound kind.
Scale
The flaky black oxide that forms on hot steel. It is lost material and it will hammer into your surface if you let it.
Seax
The single-edged Germanic and Anglo-Saxon utility knife, often with a broken-back spine. The best first project.
Slack tub
The water bucket at the anvil, for cooling tools and tongs — not for quenching blades.
Stock removal
Making a blade by grinding it from bar stock rather than forging it. Entirely legitimate; most fine knives are made this way.
Strop
Leather, often loaded with abrasive compound, used edge-trailing to remove the last burr and align the apex.
Tamahagane
The bloomery steel from a Japanese tatara furnace, sorted by carbon content before forging.
Tang
The unsharpened extension of the blade that runs into the handle. Where most blades fail.
Tempering
Reheating a hardened blade to a low temperature to trade some hardness for toughness. Mandatory, and within the hour.
Throat
The mouth of a scabbard, where friction holds the blade.
Tuyere
The pipe that delivers air into a solid-fuel forge.
Wootz
The historical South Asian crucible steel with a watered surface pattern. The original Damascus.
Work hardening
The stiffening of metal from being worked cold. In armouring it fights you; anneal often.
Wrought iron
Low-carbon iron with fibrous slag inclusions. Cannot be hardened, nearly impossible to break.

Questions the house is asked

Plain answers, including the ones that cost us a sale.

What the house refuses to say

  • The house will not tell you that a home-forged sword is safe for combat use, sparring, or cutting at another person. Testing a blade's safety takes destructive proof of a sibling blade from the same billet, and we cannot witness yours.
  • The house will not give you heat-treat numbers for stainless or for modern powder alloys. Those need a controlled-atmosphere kiln, plate quench, and cryogenic soak; published recipes for them in a home shop mislead more than they help.
  • The house will not appraise, authenticate, or value anything you forge. Forge Wisdom is craft knowledge, not a certificate.
  • The house will not claim these numbers replace your steel supplier's own datasheet. Where they differ, believe the mill, not us.
  • The house will not tell you what is legal to carry or sell where you live. That is your statute to read.

Once the steel is yours, keep it: the Upkeep Writ will write you a dated schedule for whatever you forged. Held to house law WB-GOV-024.

Where the craft ends

Forge your own, and the house cheers you. Until the fire is lit, these are pieces of the same patterns you have just read about, carried and measured.

Walk the whole hall →
Strength and Solidarity LLC

Because when you see that dragon,
you know it’s strong and solid.

Strength and Solidarity LLC

Warborn Trial
